Product Type: Solar Panel Mounting Systems Hardware
Product Model: Solar-Panel-Roof-Hanger-Bolts
Material: Steel, Rubber, Aluminum
Max Wind Load : 60 m/s
Max Snow Load : 1.4 KN / M 2
Application: Solar Panels Roofing Installation
Our solar hanger bolts are a SUS304 fasten parts to fixed rails and roofing mountings .
Two length 200mm and 250mm options can be suitable for adjust distance between brackets / L foot rails and metal roofing .
Our whole hanger bolt lits includes : stainless steel bolt , nuts, EPDM rubber and fasten L foot / small stainless plate …
This solar hanger bolts are designed for trapezoidal / zinc / corrugated / sandwich metal roof profiles .
Our hanger bolts can be pre-assembled with listed parts which consist of : one hanger bolts, 3 collar nuts with riffle, 1 washer, 1 SUS 304 plate with long slot , EPDM nodes .
This solar roof fasten bolts can be well used with adapter plates, L-feet for solar mounting and racking systems .
Our EPDM plasic grommet are good performance in bad weather as roof seal, 12 years warranty offer .
Features of our PV module hanger bolts:
– 7 3/4″ and 9 3/4″ length for choosing ;
– Good load bearing capacity ;
– Quick mounted installation hardware, fast fit system ;
– Precise adjust deepth and height for metal roofs ;
– Well span gap controlled by our longer hanger bolt for roof structure ;
– Includes bolt, rubber pad, flange nuts, support plate ;
– Application: metal roofing , trapezoidal roofs, corrugated metal sheet roofing, sandwich fiber roof, tin roofs …
Installation Guide :
Components includes for roof fastening with our hanger bolt kits, double hanger bolts,L bracket, mounting rails, mid / end clamps .
(1) Pre-drilled hole on metal roofing profile and wood rafter ;
(2) Screw in hanger bolts , the EPDM seal should slightly compressed roof surface ;
(3) Adjust adapter plate to proper height, then fasten locking nuts well ;
(4) Mounting aluminum rails and rail splice ;
(5) Mounting mid / end clamps .
Requirements to design and quote
1) solar panel datasheet (L x W x T)
2) planed layout: ___row X ___nos modules
3) tile angle
4) roof type: metal or tile or concrete
5) orientation of solar panel: portrait or landscape
6) wind load and snow load
Why Choose US
· Design conformable to different on-roof project requirements
· Fast and cost effective installation, easy to be assembled on different roof tops
· Short in 7 days leading time
· Wisely solutions for your solar PV projects
FAQ
Q : Can I have a sample order ?
A : Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q : What about the lead time?
A : Sample needs 3-5 days, mass production time needs 10~20 days for order quantity more than.
Q : Do you have any MOQ limit ?
A : For normal products,we provide low MOQ, 1pc for sample checking is available.
Q : How do you ship the goods and how long does it take to arrive?
A : For small products,we usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-7 days to arrive. For big orders,we usually ship by sea,it will take 7~30days to arrive, depend on distance.
Q : How to proceed an orders?
A : Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.
Q : Is it OK to print my logo on products?
A : Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q : Do you offer guarantee for the products?
A : Yes, we offer 10 years to solar mounting system.
